AC Test Transformer System (Oil Insulated Type)

Name: AC Test Transformer System (Oil Insulated Type)
Brand: Guangdong Yufeng Industries Co., Ltd.
Availability: InStock
Rating: 4.4 (1 reviews)

It is specially designed for low capacitive load or inductive load high voltage tests, and can supply stable test voltage even if the test load capacitance changes during the test, just like pollution test and wet test, etc. it can be applied for factory test & type test of power transformer, bushing, surge arrestor, instrument transformer, and gis. Product design conforms to the IEC standard.

GET A QUOTE

Features of AC Test Transformer System (Oil Insulated Type)

With module structure designing, it is very flexible to have serial or parallel connections for meeting kinds of applications.
With powerful overvoltage protection and high safety design for operation.
With a digital control system, optical fiber communication, and excellent EMC design.
With non-pd design and high reliability.

Main Components of AC Test Transformer System (Oil Insulated Type)

Cylinder or tank type of test transformer
High voltage divider and coupling capacitor
HV filter
Regulating transformer
Compensating reactor
Digital control system

System Model Sheet of AC Test Transformer System (Oil Insulated Type)

MODEL	CAPACITY	RATING VOLTAGE	RATING CURRENT	FREQUENCY
YDTW-100/100	100KVA	100kV	1A	50Hz
YDTW-150/150	150KVA	150kV	1A	50Hz
YDTW-200/200	200KVA	200kV	1A	50Hz
YDTCW-500/250	500KVA	250kV	2A	50Hz
YDTCW-600/300	600KVA	300kV	2A	50Hz
YDTCW-500/2X250	500KVA	500kV	1A	50Hz
YDTCW-600/2X300	600KVA	600kV	1A	50Hz

(Note: Upper is just for reference, additional models can be customized according to customer requirements)
