HV DC Generator Test System

Name: HV DC Generator Test System
Brand: Guangdong Yufeng Industries Co., Ltd.
Availability: InStock
Rating: 4.4 (1 reviews)

It is specially designed for HVDC high voltage test and can supply stable test voltage it can be applied for factory test & type test of DC cable, DC GIS, power transformer, bushing, and so on, and product design conforms to the IEC standard.

GET A QUOTE

Features of HV DC Generator Test System

With module structure designing, it is very flexible to have serial or parallel connections for meeting kinds of applications.
With powerful overvoltage protection and high safety design for operation.
With a digital control system, optical fiber communication, and excellent EMC design.
With non-pd design and high reliability.

Main Components of HV DC Generator Test System

HVDC generator
Damping resistor
HV divider
Isolation transformer Digital control system

System Model Sheet of HV DC Generator Test System

MODEL	RATING VOLTAGE	RATING CURRENT	RIPPLE FACTOR
SLDC-200	+/-200KV	5 to 50mA	≤3%
SLDC-400	+/-400KV	5 to 50mA	≤3%
SLDC-500	+/-500KV	5 to 50mA	≤3%
SLDC-600	+/-600KV	5 to 50mA	≤3%
SLDC-800	+/-800KV	5 to 50mA	≤3%
SLDC-1000	+/-1000KV	5 to 50mA	≤3%
SLDC-1200	+/-1200KV	5 to 50mA	≤3%
SLDC-1500	+/-1500KV	5 to 50mA	≤3%

(Note: Upper is just for reference, additional models can be customized according to customer requirement)
