Variable Frequency Resonance Test System(Gas Insulated Type)

Name: Variable Frequency Resonance Test System(Gas Insulated Type)
Brand: Guangdong Yufeng Industries Co., Ltd.
Availability: InStock
Rating: 4.4 (1 reviews)

Variable frequency resonance test system is specially designed for field tests of GIS from 110kV to 750kV and can be used for withstanding voltage test and PD test, and it can meet the IEC standard.

GET A QUOTE

Features of Variable Frequency Resonance Test System(Gas Insulated Type)

With Gas insulated design, it is very flexible to connect with GIS by flange connection
With a compatible design, it is easy to move and load & unload during use.
With a friendly operation interface, is easy to operate during working variable frequencies between 30 to 300Hz
Low partial discharge designing

Main Components of Variable Frequency Resonance Test System(Gas Insulated Type)

Variable frequency converter
Excitation transformer
Gas insulated reactor
Voltage divider
Bushing for testing (optional)
Remote control system (optional)

System Model Sheet of Variable Frequency Resonance Test System(Gas Insulated Type)

MODEL	CAPACITY	RATING VOLTAGE	RATING CURRENT	FREQUENCY
SLPYK-600/300	600kVA	300kV	2A	30 to 300Hz
SLYFK-800/400	800kVA	400kV	2A	30 to 300Hz
SLYFK-1000/500	1000kVA	500kV	2A	30 to 300Hz
SLYFK-1100/550	1100kVA	550kV	2A	30 to 300Hz
SLYFK-1200/600	1200kVA	600kV	2A	30 to 300Hz
SLYFK-1500/750	1500kVA	750kV	2A	30 to 300Hz
SLYFK-1800/900	1800kVA	1800kV	2A	30 to 300Hz

(Note: Upper is just for reference, additional models can be customized according to customer requirement
